| Construction Details | |
| Outer Jacket | |
| Material | No Jacket |
| Nom. Diameter | 0.420 in (10.7 mm) |
| Table Notes | Overall Cable Diameter (Nominal) |
| Banana Peel® | 0.420 in (10.7 mm) |
| Electrical Characteristics | |
| Voltage | |
| UL Voltage Rating | 300 V (CMP) |
| Mechanical Characteristics | |
| Temperature | |
| UL Temperature | 75°C |
| Operating | 0°C to +75°C |
| Bend Radius | |
| Stationary Min. | 4.2 in (110 mm) |
| Installation Min. | 4.2 in (110 mm) |
| Max. Pull Tension | 200 lbs (91 kg) |
| Bulk Cable Weight | 100 lbs/1000ft |
Notes:
Cold environment installation: When installing cables that have been stored at ambient temperatures of 32 degrees Fahrenheit (0 degrees Centigrade) or lower. Belden recommends conditioning of the cable for 12 hours at room temperature prior to individual cable leg separation.
