| Construction Details | |
| Conductor | |
| Element | Conductor(s) |
| No. of Elements | 2 |
| Size | 23 AWG |
| Stranding | Stranded |
| Material | TC - Tinned Copper |
| Insulation | |
| Material | ETFE - Ethylene Tetrafluoroethylene |
| Color Code | Black, White |
| Outer Jacket | |
| Material | PVC - Polyvinyl Chloride |
| Overall Cable Diameter (Nominal) | 4.1 mm (0.16 in) |
| Electrical characteristics | |
| Electricals | |
| Max. Conductor DCR | 74.5 Ohm/km (22.7 Ohm/1000ft) |
| Voltage | |
| UL Voltage Rating | 300 V (Max. Operating Voltage) |
| Mechanical Characteristics | |
| Temperature | |
| Operating | -40°C to +105°C |
| Table Notes | ±90º Bending: Min. 8 million cycles (Speed: 60 cycles/min.; Bending radius: 7.5D) ; Drag Chain: Min. 25 million cycles (Traversing distance: 350mm; Speed: 70 cycles/min; Bending radius: 6D) ; Vertical Torsion Test +/-180⁰/m: Min. 8 million cycles ; Horizontal Torsion Test +/-90⁰/m: Min. 8 million cycles. |
| Bulk Cable Weight | 23.5 kg/km (15.8 lbs/1000ft) |
Notes:
UL certification : UL 13. Suitability -Oil Resistant : IRM 902 120℃x18hrs, IRM 903 120℃x18hrs
